Product information "HORIBA IG-331 Gloss Checker Measuring range 0-100"
Gloss is important visual property of object's surface. The degree of light reflected from the object's surface is termed glossiness. However, the perception of glossiness is subjective and depends on the weather conditions, physical abilities of watching person etc.
HORIBA IG-331 Gloss Checker Measuring range 0-100
Handy Digital Gloss Checkers Allow Objective, Quantified Gloss Measurements
Designed for greater ease of operation, maintain clean surfaces and improve quality control inspection in various industrial applications.
High efficiency and flexibility utilizing a separate detector and light source, offers the ability to switch between 60 degree measuring angle for standard gloss measurement, and 20 degree measuring angle for high-gloss surfaces with gloss values over 70.
The flexible connection between the probe and display unit ensures greater work efficiency.
Just one touch of the calibration key starts the automatic sequential zero-span calibration.
Features:
- High efficiency measurement
- Measuring angles 20° and 60°
- Flexible use with its remote probe
Dimensions
| Height | 4,5 cm |
|---|---|
| Length | 21,5 cm |
| Width | 17 cm |
Weight
| Weight | 440 g |
|---|
Other attributes
| Country of origin | JP |
|---|---|
| Customs tariff number | 85437090 |
|
Optical system |
60° measurement: Incident angle 60°, Reception angle 60°. |
|
Measuring area |
60° measurement 3*6mm oval |
|
Light source |
LED (wavelength: 890 nm) |
|
Detector |
SPD (silicone photodiode) |
|
Measuring range |
0-100 |
|
Display range |
0-199 (resolution: 1) |
|
Repeatability |
±5% F.S. ±1 digit |
|
Power Source |
A3 dry cell battery *4 (Not rechargeable) |
|
Battery life |
50 hours or more |
|
Operating temperature |
10 - 40°C |
|
Dimensions |
Main body: 140 (W) * 75 (H) * 34 (D) mm Optical sensor: 88 (W) * 30 (H) * 45 (D) mm |
|
Weight |
Approx. 350g (with batteries) |
|
Additional functions |
|
